For 30 years the SR has given bass players a modern alternative. With its continued popularity, Ibanez is constantly endeavoring to answer the wider needs of a variety of players, at a variety of budgets. But no matter what the specs, the heart is the same-SR continues to excite with its smooth, fast neck, lightweight body, and perfectly matched electronics.
SPEC
| neck type | SR4 5pc Jatoba/Bubinga neck |
| body | Mahogany body |
| fretboard | Rosewood fretboard w/Abalone oval inlay |
| fret | Medium frets |
| number of frets | 24 |
| bridge | Accu-cast B300 bridge (19mm string spacing) |
| neck pickup | Bartolini® MK-1 neck pickup (Passive) |
| bridge pickup | Bartolini® MK-1 bridge pickup (Passive) |
| equaliser | Ibanez Custom Electronics 3-band EQ w/Mid frequency switch |
| factory tuning | 1G, 2D, 3A, 4E |
| string gauge | .045/.065/.085/.105 |
| hardware color | Cosmo black |
NECK DIMENSIONS
| Scale : | 864mm/34" |
| a : Width | 38mm at NUT |
| b : Width | 62mm at 24F |
| c : Thickness | 19.5mm at 1F |
| d : Thickness | 21.5mm at 12F |
| Radius : | 305mmR |
CONTROLS
FREQUENCY RESPONSE
