9.2-channel AVENTAGE model featuring the latest, most advanced Surround:AI, highest quality DACs, and ultimate quality XLR terminals.
- 9-channel powerful surround sound
- --- 150 W per channel (8 ohms, 20 Hz-20 kHz, 0.06% THD, 2-ch driven)
- --- 230 W per channel (4 ohms, 1 kHz, 0.9% THD, 1-ch driven)
- --- 230 W per channel (8 ohms, 1 kHz, 10% THD, 1-ch driven)
- Surround:AI automatically optimises the surround effect in real time
- Dolby Atmos® and DTS:X™ with CINEMA DSP HD3
- ESS SABRE PRO ES9026PRO Ultra DAC and SABRE ES9007S DAC
- Ability to add wireless surround speaker/s* (*MusicCast 20 or MusicCast 50)
- Amazon Alexa voice control compatibility *Amazon Echo Dot included
- Highly rigid construction including Anti Resonance Technology (A.R.T.) Wedge
- High quality parts for optimum performance
- YPAO™-R.S.C. (with 3D, multi-point measurement and 64-bit high precision EQ)
- XLR input terminal
- MusicCast multi-room technology
- Music streaming services built-in
- HDMI® (7 in / 3 out) with Dolby Vision™ and Hybrid Log-Gamma
- Phono input for vinyl playback
The AI technology built into the DSP analyses the scene of the entertainment content and then creates the optimal surround effect to reproduce it with the greatest effect. This AI instantaneously analyses scenes by focusing on distinct sound elements such as dialogue, background music, ambient sounds and sound effects, and automatically optimises the surround effect in real time, just as if a Yamaha sound engineer tunes the best sound specifically for you. This creates a compelling sense of realism with expressive power beyond conventional sound field effects, giving you the most profound entertainment experience possible.
Thrilling Realism in Surround Sound
Dolby Atmos® and DTS-X™ Playback with CINEMA DSP HD3
This AV receiver supports Dolby Atmos and DTS-X playback with CINEMA DSP HD3, taking the surround sound experience to new heights. The revamped CINEMA DSP HD3 features new signal processing algorithms and three sets of high performance processors. This maximises theatre sound effects, accurately reproducing a new dimension of realism for a sound field with a rich sense of presence and no feeling of boundaries. You will experience a realistic cinema sound field with the sense of truly being immersed in the movie scene.
Low Noise, High Resolution
ESS SABRE PRO Premier DAC™ ES9026PRO
Our flagship RX-A3080 model features ESS’s state of the art 32-bit SABRE PRO Premier DAC ES9026PRO. ESS’s patented 32-bit Hyper Stream, Total Harmonic Distortion (THD) compensation function works to minimise noise levels. In combination with the Yamaha original D.O.P.G. (DAC On Pure Ground) concept, which eliminates the potential difference between audio circuit stages to reduce ground noise, it dramatically enhances silence and resolution over the entire audio range for rich and expressive reproduction of even the most delicate sounds.
Ultimate Sound Optimisation
YPAO™ - R.S.C. (with 3D, Multi-Point Measurement and 64-bit High Precision EQ)
YPAO-R.S.C. (Reflected Sound Control) analyses the room acoustics with the included YPAO microphone to tune your system for the best sound in your unique room. It employs R.S.C. to correct early reflections for studio-quality surround sound. YPAO 3D provides automatic sound parameter optimisation that maximises the 3D sound field effectiveness of CINEMA DSP HD3 as well as Dolby Atmos and DTS:X. 64-bit high precision EQ calculation achieves the most natural room acoustics possible.
Low Noise Signal Transmission
XLR Input Terminal
The RX-A3080 comes equipped with XLR balanced audio input terminal that have an outstanding reputation in the world of professional audio and are highly sensitive to noise in the mix. In combination with a Blu-ray Disc™ player such as our BD-A1060, or CD player such as our CD-S3000 / S2100 equipped with balanced output terminal, this enables high-quality signal transmission with reduced degradation of sound quality due to external noise.
The Heart of the Smart Home.
Free and Easy Placement
Wireless Surround Speakers
Combine this AV receiver with the MusicCast 50 or MusicCast 20 wireless streaming speaker and enjoy the amazing convenience of creating a home theatre with wireless rear speakers. What’s more, you get stunningly realistic sound with a clean, clutter-free setup. Easily turn your current living room into a special entertainment environment where you can fully enjoy movies and music.
MusicCast takes the headache out of multi-room audio. Simply connect all MusicCast devices to the same network and start sharing audio throughout the home. Take MusicCast for a test drive by downloading the free MusicCast app and using it demo mode.
A World of Music
Explore a world of music with music streaming services* built-in. Syncing your playlists and song likes from your smart phone or computer to the RX-A3080, music streaming services make it impossibly easy to either listen to your faves or discover new music.
* Music streaming service availability varies by region.
Easily Experience 11-channel Realism
Virtual Speaker Technology
The RX-A3080 is equipped with three Yamaha original high performance DSP devices, achieving high speed and large capacity audio signal processing. As a result, CINEMA DSP HD3 playback can reproduce up to 11-channel sound — on even a 7-channel system. The total reproduction of spatial data, including the vertical axis, helps create an overwhelmingly realistic sound field.
* Requires connection to a front presence speaker. Dolby Atmos and DTS: X signals cannot be used with these virtual features.
Three HDMI Outputs
Since the RX-A3080 has three HDMI output terminals, simultaneous connection to the TV, LCD projector and other devices, is possible. Which means, for example, that you can use your TV as usual but use the projector for your favourite movies and special programming, or have the same main room content shown in other rooms as well — easily and without having to change any connections. Naturally, the built-in HDMI functionality is of the latest specifications, corresponding also to HDR (Dolby Vision Compatible, Hybrid Log-Gamma), 4K / 60p passthrough, 4K upscaling, and so on.
The Joys of Vintage Vinyl
This AV receiver provides phono input terminals, letting you connect a turntable and enjoy music from your vinyl collection.
Enhanced Home Theatre Sound
You can add an external power amplifier (pre-main amplifier) to this AV receiver to improve and enhance the sound of your speakers. For example, using a power amplifier to drive the important front channel in home theatre gives you the added flexibility of building a system with an emphasis on sound quality
Enjoy Digital Radio
Digital Audio Broadcasting capability, with DAB and the enhanced DAB+, offers a large selection of radio stations with high sound quality. Other benefits include automatic selection of available stations from a convenient list, and helpful information display, including station name and music genre.
* Availability of DAB / DAB+ tuner function varies by region.
Intuitively Simple to Use.
Alexa on MusicCast
“Alexa, ask MusicCast to play Favourite 1 in the Kitchen.” With Alexa voice control integration, all you have to do is ask. The RX-A3080 name offers full compatibility with Amazon’s range of voice control devices. Welcome to the smart home.
* Availability of voice command control via Amazon Alexa varies by region.
Easy Operation, Detailed Settings
AV Controller App
This easy-to-use app lets you conveniently and ‘smartly’ control your AV receiver’s power, volume, input selections, DSP modes — and much, much more — from an iOS or Android™ device. You can also use as many as 23 different languages and customise the interface by hiding unused icons and renaming functions. A tablet version is also available.
Easy to Use and Multilingual
Advanced Graphical User Interface
The latest graphical user interface from Yamaha has a high-resolution display with clear, easy-to-use menus and includes a selectable status bar that shows input source, volume level, DSP mode and audio format. The GUI provides a choice of eight languages: English, French, German, Spanish, Italian, Russian, Japanese and Chinese and can be displayed over both normal and 3D pictures.
Playback in Multiple Zones
Advanced HDMI Zone Switching
You can transmit the video or audio content (not only HDMI input, but also other audio sources, such as digital or analogue audio, network content and FM/DAB radio) to a TV or home theater system in another room (Zone 2/4). This lets you enjoy viewing and listening to the same main room content (where the AV receiver is installed), or even different content. An on-screen graphical user interface makes it easy to browse and select content from the second zone no matter what is being played in the main zone.
Even Higher Quality Sound
This AV receiver features bi-amping capability, driving the treble and bass ranges of the front speakers (L, R) with independent amplifiers, making it possible to enjoy even higher quality sound from the front channels — an important consideration in home theatre setups.
Brilliant and Lively
The Compressed Music Enhancer from Yamaha is now optimised for Bluetooth audio transmissions to ensure that your music will have vivid, energetic sound quality during wireless playback.
Install with Ease
AV Setup Guide
This special app assists you with cable connections between the AV receiver and source devices. Additionally, it guides you through various settings such as speaker connections, TV and source device connections and power amplifier assignments.
Save Energy by 20%
When ECO Mode is turned on it can reduce power consumption by about 20 percent*, thanks to an advanced energy saving design. *Compared to power consumption when ECO mode is off (Yamaha measurement).
|Rated Output Power (1kHz, 1ch driven)||230 W (4 ohms, 0.9% THD)|
|Rated Output Power (20Hz-20kHz, 2ch driven)||150 W (8 ohms, 0.06% THD)|
|Maximum Effective Output Power (1kHz, 1ch driven) (JEITA)||230 W (8 ohms, 10% THD)|
|Dynamic Power per Channel (8/6/4/2 ohms)||175 / 220 / 295 / 410 W|
|Surround Sound Processing||Surround:AI||Yes|
|CINEMA DSP||Yes (HD3)|
|Dialog Level Adjustment||Yes|
|Virtual Presence Speaker||Yes|
|Virtual Surround Back Speaker||Yes|
|Dialogue Lift||Yes (no presence speakers required)|
|SILENT CINEMA / Virtual CINEMA DSP||Yes (Virtual CINEMA FRONT)|
|Dolby Digital Plus||Yes|
|DTS-HD Master Audio||Yes|
|Audio Features||File Format||MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz|
|Pure Direct||Yes (with video on mode)|
|Compressed Music Enhancer||Yes|
|High-resolution Music Enhancer||Yes|
|YPAO multi-point measurement||Yes with R.S.C. (Reflected Sound Control) , 3D, 64-bit High Precision EQ Calculation and Angle Measurement|
|Adaptive DRC (Dynamic Range Control)||Yes|
|Initial Volume & Maximum Volume Setting||Yes|
|Audio Delay||Yes (0-500 ms)|
|DA Converter||ESS 384 kHz / 32-bit SABRE PRO Premier DAC™ ES9026PRO (for main 7 channels)|
|Video Features||4K Ultra HD Pass-through and upscaling||Yes (4K / 60p, 4:4:4)|
|HDMI 3D passthrough||Yes|
|HDMI eARC||Yes (via future firmware update)|
|HDMI Audio Return Channel||Yes|
|HDMI upscaling||Yes (Analogue to HDMI® / HDMI to HDMI)|
|Deep Colour/x.v.Colour/24Hz Refresh Rate /Auto Lip-Sync||Yes|
|HDMI Input/Output||7 / 3 (HDCP2.2, HDR10 / Dolby Vision / HLG and BT.2020 compatible)|
|HDMI CEC||Yes (SCENE, Device Control)|
|USB Input||USB Memory, Portable Audio Player|
|Wi-Fi||Yes (2.4 / 5 GHz)|
|Bluetooth||Yes (SBC / AAC)|
|Front AV Input||USB / Analogue Audio|
|Digital Audio Input/Output: Optical||3 / 0|
|Digital Audio Input/Output: Coaxial||3 / 0|
|Analog Audio Input/Output||10 (front 1) / 0|
|Component Video Input/Output||2 / 0|
|Composite Video Input/Output||4 / 0|
|Tuner Section||FM/AM Tuner||Yes (FM only)|
|DAB Tuner||Yes (Availability varies by region.)|
|User Interface||On-screen display||Graphical User Interface|
|SCENE||SCENE PLUS (8 sets)|
|App Control||Yes (iPhone / iPad / Android phone / tablet)|
|Web Browser Control||Yes|
|Remote Control Unit||Yes (Preset)|
|Zone Control||Zone 2 Audio Output||Preout / HDMI|
|Zone 3 Audio Output||Preout|
|Zone 4 Audio Output||HDMI|
|Powered Zone||Zone 2 / 3|
|Zone Video Output||HDMI / Component / Composite|
|Zone HDMI||Yes (Advanced HDMI Zone Switching)|
|Zone B Output||HDMI|
|+12V Trigger Output||2|
|Remote (IR) Input/Output||1 / 1|
|General||Standby Power Consumption (IR only)||≤0.1W|
|Auto Power Standby||Yes|
|Dimensions (W x H x D)||435 x 192 x 474 mm (with antenna up: 435 x 269 x 474 mm)|
